Non sparking tools Al-br adjustable wrenches

    Buy cheap Non sparking tools Al-br adjustable wrenches from wholesalers

    Buy cheap Non sparking tools Al-br adjustable wrenches from wholesalers
    • Buy cheap Non sparking tools Al-br adjustable wrenches from wholesalers

    Non sparking tools Al-br adjustable wrenches

    Ask Lasest Price
    Brand Name : TUOKAEX
    Certification : ISO9001
    Model Number : TK125
    Delivery Time : 15days
    Payment Terms : T/T,L/C
    Supply Ability : 10000pcs/week
    • Product Details
    • Company Profile

    Non sparking tools Al-br adjustable wrenches

    Safety non sparking spanner,Adjustable Wrench,Al-Cu Be-Cu




    1. Safety non sparking spanner,Adjustable Wrench,Al-Cu Be-Cu

    2.aluminum bronze material

    3.die forged processing

    4.own factory

    5.ISO9001 certification


    Specification:

    Number

    L
    mm

    K
    min

    Be-Cu
    g

    Al-Cu
    g

    TK125-02
    TK125-04
    TK125-06
    TK125-08
    TK125-10
    TK125-12
    TK125-14
    TK125-16

    100
    150
    200
    250
    300
    375
    450
    600

    13
    18
    24
    30
    36
    46
    55
    65

    33
    135
    281
    440
    720
    1410
    2261
    4705

    30
    120
    255
    401
    655
    1290
    2065
    4301


    Composition:

    Beryllium copper: GBExC

    Be: 1.8% - 2.3%

    Ni: 0.2% - 0.5%

    Others: < 0.5%

    Cu: Rest

    Hardness: 35-40 HRC (HB283-365)

    Tensile Strength: 1117 N/mm2 ~ 1326 N/mm2

    Aluminum bronze: GBExB

    Al: 10% - 12%

    Ni: 4% - 6%

    Fe+Mn: < 5.8%

    Cu: Rest

    Hardness: 20-30 HRC (HB229-291)

    Tensile Strength: 782 N/mm2 ~ 989 N/mm2



    The processing procedure

    Al-bronze (HRC≥25°b>75-85kgf/mm² )

    Be-bronze(HRC≥35°b>105-120kgf/mm²)

    1) To prepare the raw material, blanking

    2) Smelting

    3) Pouring

    4) Cut the water gap

    5) Stored in the semi finished products warehouse

    6) Punching

    7) Through the drawbench or slotting machine

    8) PE plain end and chamfering

    9) Drill hole

    10) Perfect the product and marking

    11)If Be-bronze, need heat treatment

    12) Polishing

    13) Surface treatment

    14)Stored in the finished products warehouse
